Features
* Support bilingual control, both Chinese and English
* Single MIC Access
* Support AEC echo elimination, steady-state noise reduction
* Support to wake up from learning, no need to compile firmware
* Comprehensive recognition rate can reach more than 98%
* Identification time is less than 100ms
* Extremely low error rate
* Entry corpus up to 150

Kernel Introduction
* Integrated 32bit RISC kernel, frequency up to 240MHz
* Support for DSP instruction sets and FPU floating point arithmetic units
* FFT Accelerator: Maximum Support 1024 points FFT / IFFT operation, or 2048 points FFT / IFFT operation
* Unisound Equation Customized Logo Algorithm
* Built-in 242KB high speed SRAM
* 8kb ROM for boot
* Built-in 2MB SPI Flash
* Support 1 road simulation MIC input, SNR ≥ 94dB
* Support for dual channel DAC output
* Built-in 5V to 3.3V, 3.3V 1.2V LDO is power supply for chip
* Provide complete RTOS-based SDK

VC-01/02-Kit has two methods for firmware upgrade , JTAG debugger program and serial port program.
JJTAG debugger uses VC series dedicated JTAG debugger, Jlink series debugger are not supported,The firmware file name being used is:uni_app_release.bin
Serial port program is USB program mode (module requires external TTL to USB module access to TX1 and RX1), the firmware file name being used must be uni_app_release_update.bin (cannot rename for ‘uni_app_release.bin’), make sure to use the “build.sh update” instruction to compile.
