Features:
Core
• Ultra-high speed 8051 Core with single clock per machine cycle, which is called 1T and the speed is about 12 times faster than traditional 8051
• Fully compatible instruction set with traditional 8051
• 19 interrupt sources and 4 interrupt priority levels
• Online debugging is supported
Operating voltage
• 1.9 to 5.5V
• Built-in LDO
Operating temperature
• -40°C~85°C
Flash memory
• Up to 33Kbytes of Flash memory to be used for storing user code
• Configurable EEPROM size, 512bytes single page erased, can be repeatedly erased more than 100 thousand times.
• In-System-Programming, ISP in short, can be used to update the application code, no need for programmer.
• Online debugging with single chip is supported, and no emulator is needed. The number of breakpoints is unlimited theoretically.
SRAM
• 128 bytes internal direct access RAM (DATA, use keyword data to declare in C language program)
• 128 bytes internal indirect access RAM(IDATA, use keyword idata to declare in C language program)
• 1024 bytes internal extended RAM (internal XDATA, use keyword xdata to declare in C language program)
Clock
• Internal high precise RC clock (IRC for short, ranges from 4MHz to 38MHz), adjustable while ISP and can be divided to lower frequency by user software, 100KHz for instance.
– Error:±0.3%
– -1.35% ~ +1.30% temperature drift (at the temperature range of -40°C to +85°C))
– -0.76% ~ +0.98% temperature drift (at the temperature range of -20°C to 65°C)
• Internal 32KHz low speed IRC with large error
• External 4MHz~33MHz oscillator or external clock
• The three clock source above can be selected freely by used code.

===========================================
