Sensor Temperature contactless, infrared

Features and Benefits:

Module model : GY-901
Use chip: MLX90614
Power supply: 3-5v (internal low dropout voltage regulator)
Size : 11x17mm
Detection distance : 1cm ~ 15cm
Communication method: standard IIC communication protocol
Small size, low cost
Mounted on a breakout board with two types of pins
10k Pull up resistors for the I2C interface with optional solder jumpers
Easy to integrate
Factory calibrated in wide temperature range:
-40 ~ +125°C for sensor temperature and
-70 ~ +380°C for object temperature.
High accuracy of 0.5°C over wide temperaturerange (0 ~ +50°C for both Ta and To) High (medical) accuracy calibration
Measurement resolution of 0.02°C
Single and dual zone versions
SMBus compatible digital interface
Customizable PWM output for continuousreading
Simple adaptation for 8 ~ 16V applications
Sleep mode for reduced power consumption
Different package options for applications andmeasurements versatility
Automotive grade
