– 1-Wire Interface Requires Only One Port Pin for Communication
– 64-Bit Serial Code Stored in an On-Board ROM
– Multidrop Capability Simplifies Distributed Temperature-Sensing Applications
– Requires No External Components
– Can Be Powered from Data Line; Power Supply Range is 3.0V to 5.5V
– Measures Temperatures from -55°C to +125°C (-67°F to +257°F)
– ±0.5°C Accuracy from -10°C to +85°C
– Thermometer Resolution is User Selectable from 9 to 12 Bits
– Converts Temperature to 12-Bit Digital Word in 750ms (Max)
– User-Definable Nonvolatile (NV) Alarm Settings
– Software Compatible with the DS1822
– Applications Include Thermostatic Controls,Industrial Systems, Consumer Products,
Thermometers, or Any Thermally Sensitive System
